MULTISHOWER SYSTEM COMBI-EXCLUSIVE
|
|
| MULTISHOWER MODEL COMBI - EXCLUSIVE GENERAL DESCRIPTION |
| 1 |
Main control unit /hydromassage tribune/charcot shower / scotch hose
|
1pc |
| 2 |
Shower systems
|
5pcs |
| 3 |
Automatic Thermixer
|
1pc |
| NOTE: All shower systems included into Multishower could be used simultaneousely or as a stand alone shower. |
|
|
|
MULTISHOWER MODEL COMBI - EXCLUSIVE SPECIFICATION / TECHNICAL DATA
|
| 1 |
Special automatic thermixing system for automatic temperature control. Housing with chrome plated fittings and elements, ID 1 1/2". |
1pc |
| 2 |
MSE /D-05/04 Special water distributing system. Equpped with individual pressure / temperature gauges (6pcs), individual shut-off valves (5pcs) . High gloss acrylic housing . Fittings: chrome / PVD Gold.
DIMENSIONS: 33" (W) 83cm x 24" (H) 60cm x 7.8" (D) 20cm
|
1pc |
| 3 |
Main Control Unit / Hydromassage Trubune/ Charcot Shower/ Scotch Hose. Equipped with control valves - 6pcs, pressure / temperature gauge - 1pc, chrome plated fittings&components, clear screen. |
1pc |
| 4 |
Affusion /Vichy Shower VO-7 Standard Chrome MSE/D |
1pc |
| 5 |
Swiss Shower Standard MSE/D |
1pc |
| 6 |
Cascade Shower CS-1 Standard MSE/D |
1pc |
| 7 |
Low Stool MSE/D |
1pc |
|
|
|
MULTISHOWER SYSTEM COMBI-DELUXE
|
|
|
|
|
|
|
|
|
| 1 |
Main control unit /hydromassage tribune /charcot shower / scotch hose
|
1pc |
| 2 |
Shower systems (3 to 9 upon customer's requirements)
|
3 to 9 |
| 3 |
Automatic Thermixer*
|
1pc |
NOTE: All shower systems included into Multishower could be used simultaneousely or as a stand alone shower system.
* Not available with mineral and sea water systems.
NOTE 2:Custom design for use with sea and mineral water is available. Contact for details.
|
|
|
MULTISHOWER MODEL COMBI - DE-LUXE
SPECIFICATION / TECHNICAL DATA
|
| 1 |
Special automatic thermixing system for automatic temperature control. Housing with chrome plated elements (N/a with sea and mineral water custom design) |
1pc |
| 2 |
Special water distribution system. High gloss acrylic housing; polished chrome & PVD gold elements and fittings. DIMENSIONS: 33" (W) 83cm x 24" (H) 60cm x 7.8" (D) 20cm |
1pc |
| 3 |
Main Control Unit /Hydromassage Tribune/Charcot Shower/ Scotch Hose |
1pc |
| 4 |
Showers 3-9. Choice of cascade, swiss, affusion /vichy showers, PES-15, Low Stool or Sit Bath. |
|
|
|
MULTISHOWER SYSTEM COMBI-REGULAR
|
|
|
|
MULTISHOWER MODEL COMBI - REGULAR (4 SHOWERS)
|
| 1 |
Main control unit /hydromassage tribune/ charcot shower / scotch hose
|
1pc |
| 2 |
Shower systems (Swiss Shower, Head Rain Shower, Low Stool or Sit Bath)
|
3 |
| 3 |
Automatic Thermixer
|
1pc |
NOTE: All shower systems included into Multishower are designed for simultaneous use or stand alone use.
NOTE 2: Custom design for use with sea and mineral water is available Contact for details.
|
|
|
SPECIFICATION / TECHNICAL DATA MULTISHOWER MODEL COMBI - REGULAR
|
| 1 |
Special automatic thermixing system for automatic temperature control. Housing with chrome plated elements and fittings. |
1pc |
| 2 |
MSR- 4 Special water distribution system. Equipped with individual pressure / temperature gauges (4pcs) and individual shut-off valves. High quality polished acrylic housing with accessories color PVD gold, polished chrome. DIMENSIONS: 33" (W) 83cm x 24" (H) 60cm x 7.8" (D) 20cm |
1pc |
| 3 |
Main Control Unit /Hydromassage Tribune/Charcot Shower/ Scotch Hose |
1pc |
| 4 |
Swiss Shower Standard |
1pc |
| 5 |
Head Rain Shower |
1pc |
| 6 |
Low Stool or Sit Bath (optional) |
1pc |
|
|
|
OPTIONS FOR MODEL COMBI-REGULAR
|
| 1 |
Sit / Hip Bath
|
1pc |
| 2 |
Clear protective screen for shower tribune / Main Control Unit
|
1pc |
|
|
